HOME > Industrial Oil Filtration > JY-RSM Membrane separation and purification system

JY-RSM Membrane separation and purification system

Contact now

Consultation telephone +8613889310698

JY-RSM Membrane separation and purification system

Reliable products and customized solutions optimize systems and production processes.

JINGYUAN RSM membrane separation and purification system is a modular design product, is a new generation of membrane separation technology, RSM in the separation and purification process does not occur phase change, no chemical reaction, so low energy consumption, no need to add other materials from the outside to help separation and purification; According to the selective permeability characteristics of the membrane and the size of the membrane pore size, the substances of large molecules and small molecules can be separated, so that the oil can be purified without changing their original properties, which is pure physical separation and purification and decolorization. Wafer RSM membrane separation and purification decolorization system has strong adaptability, processing scale can be large or small, convenient operation and maintenance, customers can customize this product according to different needs.

Technical indicators:

Model: JY-RSM50

Flow rate: 50L/h

Filter area: 22m2

Filter membrane: wafer composite ultrafiltration membrane

Working pressure: 0.1~0.35Mpa

Operating temperature: 50-60°C

Cleaning method: clean oil circulation cleaning / aviation kerosene cleaning / chemical cleaning agent

Prefiltering: Y

Inlet and outlet pipe diameter: DN25(1′)

Applicable oils: waste hydraulic oil, lubricating oil, crude oil, base oil or near oil

Size: 800×500×1860mm

Weight: 180Kg

Peculiarity:

1. Purification or decolorization of waste hydraulic oil, lubricating oil, crude oil, base oil.

2. Clarification filtration and filtration of visible particles.

3. Long service life.

4. High efficiency, energy saving, environmental protection, overall safety, reliability and compliance.

5. Modular design, compact, flexible, more convenient installation, use and maintenance, compact design, small footprint.

FAQ

Are you a factory or a distributor?

Hello, we are a production manufacturer, JINGYUAN is a company specializing in the production and supply of membrane filtration materials, industrial filtration equipment. It can provide customers with professional filtration equipment to help customers solve various filtration problems.

What is the core technology of your factory?

Hello, JINGYUAN membrane filter materials have been used in the field of filtration and separation for more than ten years, from petroleum products to industrial filtration applications, JINGYUAN membrane filter materials have excellent results. JINGYUAN's membrane products offer surface and depth filtration capabilities, and their polymer porous structure consists of non-directional diffusion media units that optimize filtration efficiency to match liquid filtration and separation requirements.

Is it necessary to use diesel filter purifiers at oil depot gas stations?

A diesel filter is a device used to filter impurities, gums and particulate matter in diesel fuel, and its importance is self-evident. It can be applied to industrial sites such as refineries, oil depots and gas stations to guarantee high standards of diesel quality. Wafer diesel filters are a very important piece of equipment, and diesel filters are increasingly used in industrial sites such as refineries, oil depots and gas stations. It can guarantee the high standard and high quality of diesel, prevent impurities and particles in diesel to cause damage to the engine, and has good filtration efficiency and long life.

Why is the quality of diesel fuel so important?

The quality of diesel fuel is important because it can affect the performance and service life of diesel engines. High-quality diesel fuel can improve the combustion efficiency of the engine, thereby reducing fuel consumption and emissions. It also reduces wear and contamination inside the engine, thereby extending the life of the engine. Low-quality diesel fuel can cause engine failure, such as high combustion temperature and pressure, overheating, in-cylinder knocking, and other problems. These problems not only lead to engine damage, but also to increased emissions of pollutants. Therefore, it is very important to use high-standard, high-quality diesel fuel.

Why should industrial oil be filtered?

There are many reasons to filter oil. An important reason is that filtration removes impurities and contaminants from oil. The oil may contain tiny particles, dirt and sludge that can cause damage to the machine, so filtration protects the operation of the machine. In addition, filtration can also improve the performance and life of the oil. After filtration, the oil can maintain good flow and lubricity for longer, thus extending the life of the machine.
