JY-G100 Lubricating oil purification filter

JY-G100 is specially designed for filtering industrial oil products. It can be used to filter new oil, pump the oil stored in the oil tank to the system oil tank, purify the oil in use, and improve the oil in the existing system. Liquid filtration performance, can be used for the purification and fine filtration of hydraulic oil, gear oil and lubricating oil.

Contact now

Consultation telephone +8613889310698

JY-G100Lubricating oil purification filter/Portable Oil Purifier Cart/ Lube Oil Filter Cart

Reliable, consistent, and verifiable filtration performance.

JY-G100 is specially designed for filtering industrial oil products. It can be used to filter new oil, pump the oil stored in the oil tank to the system oil tank, purify the oil in use, and improve the oil in the existing system. Liquid filtration performance, can be used for the purification and fine filtration of hydraulic oil, gear oil and lubricating oil.

Technical specifications:

Model: JY-G100
Flow rate: 20～60L/min
Filtration accuracy: 2～25μm
Filter material: Jingyuan polymer membrane material
Working pressure: 0.2～0.3Mpa
Applicable oil: hydraulic oil, engine oil, gear oil (petroleum or mineral base oil)
Viscosity: 320# gear oil can be filtered
Power supply: 380v
Dimension: 800×750×1350mm
Weight: 115kg

China Oil Purifier Manufacturer-jingyuan^®

Oil Purification Systems
lube oil filtration
Lubrication Oil Filters
Lube Oil Filter Cart
Hydraulic & Lubrication Oil Filters
Lube Oil Treatment System
Hydraulic Oil Filtration Machine
Gear Oil Filtration Machine
Portable Oil Purifier Cart
Industrial Filtration Equipment

In any case, the working medium should enter the system through a fine filter

Benefits :

Prevents trouble to the hydraulic equipments
Improves machine reliability and productivity
Longer life of all hydraulic components, pumps, servo-valves and other equipment
Very important reduction of oil consumption and the resulting waste oil
Inline filter life extended

The necessity of oil filtration

Solid particle contaminants are the most common factor leading to failure and shutdown of hydraulic and lubrication systems, so industrial oil must be filtered and purified before being injected into the system. The pollution degree of unpurified new oil often exceeds the requirements of actual hydraulic system oil regulations. Since new oil has a high initial pollution level, most new oil (even if it is just extracted from an oil tank) is not suitable for direct use. There are many reasons for the pollution of new oil. Various pollutants, no matter particles or moisture, may be mixed into the new oil during processing, mixing and storage.

FAQ

Are you a factory or a distributor?

Hello, we are a production manufacturer, JINGYUAN is a company specializing in the production and supply of membrane filtration materials, industrial filtration equipment. It can provide customers with professional filtration equipment to help customers solve various filtration problems.

What is the core technology of your factory?

Hello, JINGYUAN membrane filter materials have been used in the field of filtration and separation for more than ten years, from petroleum products to industrial filtration applications, JINGYUAN membrane filter materials have excellent results. JINGYUAN's membrane products offer surface and depth filtration capabilities, and their polymer porous structure consists of non-directional diffusion media units that optimize filtration efficiency to match liquid filtration and separation requirements.

Is it necessary to use diesel filter purifiers at oil depot gas stations?

A diesel filter is a device used to filter impurities, gums and particulate matter in diesel fuel, and its importance is self-evident. It can be applied to industrial sites such as refineries, oil depots and gas stations to guarantee high standards of diesel quality. Wafer diesel filters are a very important piece of equipment, and diesel filters are increasingly used in industrial sites such as refineries, oil depots and gas stations. It can guarantee the high standard and high quality of diesel, prevent impurities and particles in diesel to cause damage to the engine, and has good filtration efficiency and long life.

Why is the quality of diesel fuel so important?

The quality of diesel fuel is important because it can affect the performance and service life of diesel engines. High-quality diesel fuel can improve the combustion efficiency of the engine, thereby reducing fuel consumption and emissions. It also reduces wear and contamination inside the engine, thereby extending the life of the engine. Low-quality diesel fuel can cause engine failure, such as high combustion temperature and pressure, overheating, in-cylinder knocking, and other problems. These problems not only lead to engine damage, but also to increased emissions of pollutants. Therefore, it is very important to use high-standard, high-quality diesel fuel.

Why should industrial oil be filtered?

There are many reasons to filter oil. An important reason is that filtration removes impurities and contaminants from oil. The oil may contain tiny particles, dirt and sludge that can cause damage to the machine, so filtration protects the operation of the machine. In addition, filtration can also improve the performance and life of the oil. After filtration, the oil can maintain good flow and lubricity for longer, thus extending the life of the machine.
