HOME > Custom Products > JY-A10 module fine filtration separation system

JY-A10 module fine filtration separation system

In any case, the working medium should enter the system through a fine filter.

Contact now

Consultation telephone +8613889310698

JY-A10 module fine filtration separation system

Tailored to your needs for optimal filtration performance

This model is a modular design product, customers can customize this product according to different flow needs, using JINGYUAN advanced membrane filtration material, can balance oil flow and filtration effect, allow maximum flow while effectively filtering targeted impurities and moisture, can achieve high efficiency under the condition of minimum back pressure and maximum flow, multi-directional uniform membrane microporous structure makes it have excellent filtration and separation performance, and can implement cleaning and backwash operations.

Technical indicators:

Model: JY-A10

Flow rate: 5-12m³/h (Max).

Filtration accuracy: 2~15μm (can be selected according to system requirements)

Filter material: JINGYUAN polymer membrane material

Working pressure: 0.2~0.35Mpa

Motor power: 2.0KW, 380V

Pump set: centrifugal pump/gear pump

Prefiltering: Y

Inlet and outlet pipe diameter: DN65 (2.5′)

Applicable oils: petroleum or mineral base oil, lubricating oil, diesel, gasoline (need to be customized)

Size: 1480×1250×2030mm

Note: The flow rate varies with the variety, quality, viscosity, equipment maintenance and other indicators of the oil, and is not an absolute value

China Oil Purifier Manufacturer-jingyuan^®

Oil Purification Systems
lube oil filtration
Lubrication Oil Filters
Lube Oil Filter Cart
Hydraulic & Lubrication Oil Filters
Lube Oil Treatment System
Hydraulic Oil Filtration Machine
Gear Oil Filtration Machine
Portable Oil Purifier Cart
Industrial Filtration Equipment
Fuel Polishing and Filtration

In any case, the working medium should enter the system through a fine filter

Benefits :

Prevents trouble to the hydraulic equipments
Improves machine reliability and productivity
Longer life of all hydraulic components, pumps, servo-valves and other equipment
Very important reduction of oil consumption and the resulting waste oil
Inline filter life extended

The necessity of oil filtration

Solid particle contaminants are the most common factor leading to failure and shutdown of hydraulic and lubrication systems, so industrial oil must be filtered and purified before being injected into the system. The pollution degree of unpurified new oil often exceeds the requirements of actual hydraulic system oil regulations. Since new oil has a high initial pollution level, most new oil (even if it is just extracted from an oil tank) is not suitable for direct use. There are many reasons for the pollution of new oil. Various pollutants, no matter particles or moisture, may be mixed into the new oil during processing, mixing and storage.

FAQ

Are you a factory or a distributor?

Hello, we are a production manufacturer, JINGYUAN is a company specializing in the production and supply of membrane filtration materials, industrial filtration equipment. It can provide customers with professional filtration equipment to help customers solve various filtration problems.

What is the core technology of your factory?

Hello, JINGYUAN membrane filter materials have been used in the field of filtration and separation for more than ten years, from petroleum products to industrial filtration applications, JINGYUAN membrane filter materials have excellent results. JINGYUAN's membrane products offer surface and depth filtration capabilities, and their polymer porous structure consists of non-directional diffusion media units that optimize filtration efficiency to match liquid filtration and separation requirements.

Is it necessary to use diesel filter purifiers at oil depot gas stations?

A diesel filter is a device used to filter impurities, gums and particulate matter in diesel fuel, and its importance is self-evident. It can be applied to industrial sites such as refineries, oil depots and gas stations to guarantee high standards of diesel quality. Wafer diesel filters are a very important piece of equipment, and diesel filters are increasingly used in industrial sites such as refineries, oil depots and gas stations. It can guarantee the high standard and high quality of diesel, prevent impurities and particles in diesel to cause damage to the engine, and has good filtration efficiency and long life.

Why is the quality of diesel fuel so important?

The quality of diesel fuel is important because it can affect the performance and service life of diesel engines. High-quality diesel fuel can improve the combustion efficiency of the engine, thereby reducing fuel consumption and emissions. It also reduces wear and contamination inside the engine, thereby extending the life of the engine. Low-quality diesel fuel can cause engine failure, such as high combustion temperature and pressure, overheating, in-cylinder knocking, and other problems. These problems not only lead to engine damage, but also to increased emissions of pollutants. Therefore, it is very important to use high-standard, high-quality diesel fuel.

Why should industrial oil be filtered?

There are many reasons to filter oil. An important reason is that filtration removes impurities and contaminants from oil. The oil may contain tiny particles, dirt and sludge that can cause damage to the machine, so filtration protects the operation of the machine. In addition, filtration can also improve the performance and life of the oil. After filtration, the oil can maintain good flow and lubricity for longer, thus extending the life of the machine.
